YUNIL NEOPS-600 Gear Skiving Machine
Have one to sell?
ConditionNew
New
POWER SKIVING MACHINE
for the machining of Internal and External Spur or Helical gears.
• Short Machining Time
• High Machining Volume
• Moderate Tool Cost
• Manufacturing of Internal & External Gearing in One Chucking
MACHINE CAPCITY
Max. Workpiece Dia. (Internal)........600mm
Max. Workpiece Dia. (External)........750mm
Max. Workpiece Height.................450mm
Max. Helix Angle (A-axis).............±30°
Max. Pitch............................module 6.0
STOKE RANGE
Radial Travel (X-axis)...............500mm (+490mm ~ -10mm)
Tool Shift Travel....................500mm (+250mm)
Z-Axis Work Range....................490mm (230mm ~ 720mm)
Table Diameter.......................Ø650
TOOL
Taper of Spindle Nose...............HSK #125
Max. Tool Shift Travel (Y-Axis).....500mm (±250)
MAIN SPINDLE MOTOR
B-Axis Spindle Motor................286Nm (33kw)
B-Axis Max. RPM.....................6000rpm
C-Axis Spindle Motor................800Nm (30kw)
C-Axis Max. RPM.....................3000rpm
