Features
• Meehanite Class FC30 casting with high rigid and wear resistance guide way insure machine permanent accuracy.
• Spindle is designed for providing excellent stability and heavy duty grinding.
• V3 grade spindle motor with good waterproof and moisture resistant design.
• Vertical feeding guide way use high rigid roller linear guideway (block x 6) provide smooth movement and rigidity.
• Work table with fine pitch magnetic chuck has powerful attractive force and specalized for small workpiece.
Rotary magnetic chuck dia.............................. 600mm
Max. grinding height................................... 300mm
Distance of table surface to spindle surface center.... 300mm
Rotary magnetic chuck speed............................ 10~100r.p.m.
Rotary magnetic chuck horse power...................... 3kw
Spindle speed.......................................... 15HP/20HP (Opt.)
Spindle speed (50/60Hz)................................ MAX 2000r.p.m.
Auto down feed horse power............................. 2kw
Feed resolution........................................ 0.0001mm
Rotary table accuracy.................................. < 0.002mm
Wheel size (ODxHxID)................................... 350x70x(3x5)x130mm
Net weight / gross weight (approx.).................... 3200/3900kg
Packing size (LxWxH)................................... 2800x2300x2280mm
※ The manufacturer reserves right to modify the design, specification mechanisms etc. without notice.
