DOWELL DSG-2450CNC Precision Rack Grinder

Table size (lxw)....................................... 600x1000mm
Distance of table surface to spindle surface center.... 400mm
Table Load............................................. 400kg
Table Spindle.......................................... 25m/min
Spindle motor.......................................... 15/20HP(Opt.)
Spindle speed(50/60HZ)................................. Max.2000r.p.m.
Vertical hand wheel down feed per graduation........... "x1,x10,x100 (MPG) /
0.001,0.01,0.1mm"
Control system......................................... Mitsubishi Control(std.)/Fanuc(Opt.)
Net weight/gross weight................................ 14000/15500kg
Packing size(LxWxH).................................... 5000x3400x3500mm

※ The manufacturer reserves right to modify the design, specification mechanisms etc. without notice.
