DOWELL VSG-3000 Vertical Long Table Precision Surface Grinder
Have one to sell?
ConditionNew
New
Features
• Vertical feeding use high stiffness box ways、precisely scraped, and Ø50mm ball screw.
• X axis use high stiffness and rigidity linear roller guideway (RG65) and block X6.
• X axis use high precision rack and pinion system for high rapid and smooth movement.
• Vertical feeding use high stiffness box ways、precisely scraped, and Ø40mm ball screw.
• X axis use linear roller guideway X3 (RG35) and block X8.
General Capacity
Table size (LxW)............................... 300x3000mm
Distance from table surface to spindle center.. 250mm
Longitudinal Movement
Servo motor feed (table speed) approx(OPT.).... 0~20M
Vertical Down feed
Increment cross feed........................... 500mm/min
M.P.G.......................................... X1：0.001mm
X5：0.005mm
X10：0.01mm
X50：0.05mm
Grinding Wheel
Wheel size (dia x width x bore)................ 140x50x25mm
Spindle speed (50/60HZ)........................ 0~1200r.p.m.
Motor
Spindle drive motor............................ 25HP
Y servo motor.................................. 2KW
X servo motor(OPT.)............................ 1.5KW
Weight
Net weight/gross weight (approx.).............. 10500/11500kg
Packing Size
Length × width × height........................ 6500x2280x2280mm
※ The manufacturer reserves right to modify the design, specification mechanisms etc.
