DOWELL VR-1000AND Vertical Rotary Surface Grinding Machine
Have one to sell?
ConditionNew
New
Features
• Meehanite Class FC30 casting with high rigid and wear resistance guide way insure machine permanent accuracy.
• Spindle is designed for providing excellent stability and heavy duty grinding.
• V3 grade spindle motor with good waterproof and moisture resistant design.
• Vertical feeding guide way use high rigid roller linear guideway (block x 6) provide smooth movement and rigidity.
• Work table with fine pitch magnetic chuck has powerful attractive force and specalized for small workpiece.
Rotary magnetic chuck dia.............................. 1000mm
Max. grinding height................................... 500mm
Distance of table surface to spindle surface center.... 400mm
Rotary magnetic chuck speed............................ 5~20r.p.m.
Rotary magnetic chuck horse power...................... 7kw
Spindle speed.......................................... 50HP
Spindle speed (50/60Hz)................................ 870/1175r.p.m.
Auto down feed horse power............................. 1.5kw
Vertical hand wheel down feed per revolution........... "x1, x5, x10(MPG)/0.1, 0.5, 1mm"
Vertical hand wheel down feed per graduation........... "x1, x5, x10(MPG)/0.001, 0.005, 0.01mm"
Wheel size (dia x width x bore)........................ 150x50x25mmx8(pcs)
Net weight / gross weight (approx.).................... 13000/14000kg
Packing size (LxWxH)................................... 5100x2950x3200mm
※ The manufacturer reserves right to modify the design, specification mechanisms etc. without notice.
