DOWELL DR-500AND Horizontal Rotary Surface Grinder
Have one to sell?
ConditionNew
New
Features
• Spindle motor adopts V3 Grade provides good water resistance and resist high humidity.
• X.Z axis feeding uses high stiffness and rigidity linear roller guides allowing smoothly X.Z feeding whilst maintaining high stiffness.
• Machine equips fine pole electrical magnetic chuck provides bigger holding power and able to attract small workpiece firmly.
Rotary magnetic chuck dia...................... 500mm
Max. grinding height........................... 250mm
Chuck max. loading............................. 100kg
Rotary magnetic chuck speed.................... 150r.p.m.
Rotary magnetic chuck horse power.............. 2kw Servo Motor
Spindle motor.................................. 7.5HP
Spindle speed (50/60Hz)........................ 1450/1750r.p.m.
Spindle axis cross feeding (per revolution).... x1, x5, x10, x50(MPG)/0.1, 0.5, 1.5mm
Spindle axis cross feeding (per graduation).... x1, x5, x10, x50(MPG)/0.001, 0.005, 0.01, 0.05mm
Wheel size (dia x width x bore)................ 355x(20~50)x127mm
Net weight / gross weight (approx.)............ 4000/4600kg
Packing size (LxWxH)(mm)....................... 3500x2300x2200mm
※ The manufacturer reserves right to modify the design, specification mechanisms etc. without notice.
