SFM SDT-40200 Heavy Duty Precision Lathe

Capacity
Swing Over Bed 1130 mm (44")
Swing Over Cross Slide 880 mm (34.7")
Swing in Gap 1400 mm (55")
Width of Gap 250 mm (10")
Distance Between Centers 5000 mm (200")

Headstock
Spindle Bore 105 mm / * 153 mm, 230 mm (OPT)
Spindle Nose A2-8 / *A2-11, D1-11, A2-15 (OPT)
Taper of Center M.T. No. 5 / * M.T. No. 6
Range of Spindle Speeds 15-1000 /*10-700 RPM
Number of Spindle Speeds 12 Changes

Feeds & Threads Cutting
Longitudinal Feeds 0.05-0.7 mm/rev
Cross Feeds 0.025-0.35 mm/rev
Inch Threads 2-28 Thread/in, (D.P. 4-56)
Metric Threads 0.8-14 mm / Thread, (M.P. 0.5-7)
Leadscrew Ø 45 mm (1-3/4") x 2 T.P.I. / * P 12 mm (OPT)

Carriage
Cross Slide Travel 585 mm (23")
Compound Rest Travel 250 mm (10")

Tailstock
Quill Diameter 105 mm (4-1/8") / * 125 mm (4-7/8")
Quill Travel 230 mm (9")
Taper of Quill Center M.T. No.6

Bed One-piece machine bed which is most suitable for heavy duty machining
Width of Bed 510 mm (20")
Main Motor 20HPx4P/*25HPx4P
Weight (Approx) 8800 kg

Packing Size
(Lx Wx H) 7000 x 1800 x 2100 mm
